型号 | 规格尺寸 (mm) | 额定风量 (m³/h) | 初阻力 （Pa） | 终阻力 （Pa） | 过滤对象 （μm） | 过滤效率 (%) | 过滤级别 |
RT-XSM7705-05 | 592*592*292 | 2200/4400 | <30/60 | <320 | ≥1 | 45% | F5 |
RT-XSM1705-05 | 287*592*292 | 1100/2200 | <30/60 | <320 | ≥1 | 45% | F5 |
RT-XSM7703-05 | 592*592*150 | 1800/3600 | <30/60 | <320 | ≥1 | 45% | F5 |
RT-XSM1703-05 | 287*592*150 | 1000/1800 | <30/60 | <320 | ≥1 | 45% | F5 |
RT-XSM7705-06 | 592*592*292 | 2200/4400 | <40/75 | <320 | ≥1 | 65% | F6 |
RT-XSM1705-06 | 287*592*292 | 1100/2200 | <40/75 | <320 | ≥1 | 65% | F6 |
RT-XSM7703-06 | 592*592*150 | 1800/3600 | <40/75 | <320 | ≥1 | 65% | F6 |
RT-XSM1703-06 | 287*592*150 | 1000/1800 | <40/75 | <320 | ≥1 | 65% | F6 |
RT-XSM7705-07 | 592*592*292 | 2200/4400 | <50/85 | <320 | ≥1 | 85% | F7 |
RT-XSM1705-07 | 287*592*292 | 1100/2200 | <50/85 | <320 | ≥1 | 85% | F7 |
RT-XSM7703-07 | 592*592*150 | 1800/3600 | <50/85 | <320 | ≥1 | 85% | F7 |
RT-XSM1703-07 | 287*592*150 | 1000/1800 | <50/85 | <320 | ≥1 | 85% | F7 |
RT-XSM7705-08 | 592*592*292 | 2200/4400 | <55/95 | <320 | ≥1 | 90% | F8 |
RT-XSM1705-08 | 287*592*292 | 1100/2200 | <55/95 | <320 | ≥1 | 90% | F8 |
RT-XSM7703-08 | 592*592*150 | 1800/3600 | <55/95 | <320 | ≥1 | 90% | F8 |
RT-XSM1703-08 | 287*592*150 | 1000/1800 | <55/95 | <320 | ≥1 | 90% | F8 |
RT-XSM7705-09 | 592*592*292 | 2200/4400 | <65/105 | <320 | ≥1 | 95% | F9 |
RT-XSM1705-09 | 287*592*292 | 1100/2200 | <65/105 | <320 | ≥1 | 95% | F9 |
RT-XSM7703-09 | 592*592*150 | 1800/3600 | <65/105 | <320 | ≥1 | 95% | F9 |
RT-XSM1703-09 | 287*592*150 | 1000/1800 | <65/105 | <320 | ≥1 | 95% | F9 |
选型指引
部件 | 外框材质 | 滤料 | 推荐厚度（mm） | 支撑架 |
描述 | 铝框/镀锌框/不锈钢框 | 合成纤维/玻璃纤维 | 铝框： 150/292 镀锌框：150/292 | 标准:镀锌铁架 |
