| Main components | Superfine glass fiber | Temperature resistance | ≤300℃ |
Filter Grade | F6-U15 | Temp short peaks | 350℃ |
Flame retardant grade | A(GB/T 17591-2006) | Moisture resistance (relative humidity) | ≤100% |
Model | Filtration Class | EFF. (0.3@5.3cm/s) | Ration (g/m2) | Thickness (mm) | I.N.P (Pa) | Longitudinal tensile Strength（MD） | Transverse tensile strength（CD） | Water resistancein （h20） | Stiffness (mg) | Combustion loss |
RT-HGF06 | M6 | ≥35% | 70±2 | 0.45±0.06 | ≤20Pa | ≥0.8 | ≥0.65 | ≥15 | ≥900 | 4.5±1.5 |
RT-HGF07 | F7 | ≥50% | 70±2 | 0.45±0.06 | ≤32Pa | ≥1.2 | ≥0.65 | ≥15 | ≥900 | 4.5±1.5 |
RT-HGF08 | F8 | ≥65% | 70±2 | 0.45±0.06 | ≤45Pa | ≥1.3 | ≥0.65 | ≥15 | ≥900 | 4.5±1.5 |
RT-HGF09 | F9 | ≥85% | 70±2 | 0.45±0.06 | ≤70Pa | ≥1.3 | ≥0.65 | ≥15 | ≥900 | 4.5±1.5 |
RT-HGF10 | H10 | ≥95% | 72±2 | 0.4±0.06 | ≤125Pa | ≥1.3 | ≥0.65 | ≥15 | ≥1200 | 4.5±1.5 |
RT-HGF11 | H11 | ≥98% | 72±2 | 0.4±0.06 | ≤180Pa | ≥1.3 | ≥0.65 | ≥15 | ≥1200 | 4.5±1.5 |
RT-HGF12 | H12 | ≥99.8% | 72±2 | 0.4±0.06 | ≤246Pa | ≥1.3 | ≥0.65 | ≥15 | ≥1200 | 4.5±1.5 |
RT-HGF13 | H13 | ≥99.97% | 74±2 | 0.4±0.06 | ≤292Pa | ≥1.3 | ≥0.55 | ≥20 | ≥1200 | 4.5±1.5 |
RT-HGF14 | H14 | ≥99.997% | 74±2 | 0.4±0.06 | ≤370Pa | ≥1.3 | ≥0.55 | ≥20 | ≥1200 | 4.5±1.5 |
RT-HGF15 | U15 | ≥99.9995% | 76±3 | 0.4±0.07 | ≤405Pa | ≥1.3 | ≥0.55 | ≥20 | ≥1200 | 4.5±1.5 |
